短圆柱连接形式。
适用于加工方形或其它异形工作。
性能可靠,经济实用。
|
尺寸参数：
| 规格D |
D1 |
D2 |
d1 |
H1 |
H |
h |
p |
Qmax |
Qmin |
Rmax |
Rmin |
B |
B1max |
B1min |
z-d |
| K51F-160 |
130 |
110 |
M16 |
70 |
113 |
4 |
20 |
16 |
6 |
38 |
33 |
30 |
1 |
-18 |
4-M10 |
| K51F-200 |
165 |
130 |
M20 |
80 |
131 |
4 |
24 |
25 |
8 |
44 |
38 |
36 |
2 |
-21 |
4-M12 |
| K51F-250 |
210 |
160 |
M22 |
95 |
155 |
5 |
28 |
31 |
10 |
57 |
50 |
39 |
4 |
-23 |
4-M14 |
| K51F-320 |
270 |
235 |
M24 |
105 |
177 |
6 |
32 |
44 |
12 |
74 |
66 |
45 |
7 |
-23 |
4-M16 |
| K51F-400 |
340 |
250 |
M24 |
115 |
199 |
6 |
45 |
68 |
13 |
76 |
67 |
43 |
12 |
-22 |
4-M20 |
| K51F-500 |
440 |
320 |
M30 |
125 |
219 |
7 |
50 |
92 |
13 |
95 |
85 |
60 |
12 |
-26 |
4-M20 |
| K51F-630 |
560 |
400 |
M36 |
150 |
263 |
8 |
55 |
119 |
11 |
120 |
108 |
79 |
15 |
-30 |
4-M24 |
性能参数：
| 规格D |
楔心套行程Lmax |
爪行程t（直径） |
许用推拉力kN |
最大夹紧力kN |
极限转速r/min |
夹紧范围 |
撑紧范围 |
净重kg |
| K51F-160 |
19 |
10 |
12 |
26 |
2800 |
20-160 |
35-160 |
12.5 |
| K51F-200 |
23 |
12 |
20 |
45 |
2300 |
20-200 |
35-200 |
23 |
| K51F-250 |
27 |
14 |
33 |
73 |
1800 |
30-250 |
45-250 |
35.5 |
| K51F-320 |
30 |
16 |
42 |
93 |
1300 |
35(50)-320 |
50(65)-320 |
55 |
| K51F-400 |
34 |
18 |
58 |
120 |
800 |
35(65)-400 |
50(80)-400 |
88 |
| K51F-500 |
38 |
20 |
110 |
220 |
600 |
40(105)-500 |
60(125)-500 |
150 |
| K51F-630 |
45 |
24 |
130 |
289 |
400 |
50(140)-630 |
70(160)-630 |
-- |
|
